SPECIFICATIONS

Applicable Material: Acrylic,Metal

Control Software: WEIHONG

Cutting Speed: 12m/min

Feature: Automated Loading

Function: Cutting Metal Materials

Key Selling Points: Long Service Life

Keyword: Fiber Laser Cutting Machiens

Laser power: 500W / 1000W / 2000W / 3000W

Laser source: Raycus IPG

Model: HJZ-1000-3015

Product name: Fiber Laser Metal Cutting Machine

Weight: 3000

Working area: 1500mm*3000mm / 2000mm*4000mm / 2000mm*6000mm

Working table: Honeycomb

brand name: HJZ

cnc or not: Yes

condition: New

configuration: Gantry Type

control system brand: Cypcut

cooling mode: WATER COOLING

cutting materials: stainless steel, carbon steel, iron, ss

cutting thickness: 6mm carbon steel

graphic format supported: AI,PLT,DXF,BMP,Dst,Dwg,LAS,DXP

guiderail brand: THK

laser type: Fiber Laser

mode of operation: Pulsed

optical lens brand: Might

place of origin: Hubei, China

products handled: Sheet Metal

servo motor brand: Huazhong

warranty: 2 Years,2 years

metal laser cutter CNC fiber laser cutting machine sheet metal 3000w

Standard Configuration of Fiber laser cutting machine:
1. German IPG Fiber laser source;
2. Japan YASKAWA Servo motor with double ball screw driving system
3. Imported World Famous "Lasermech" laser head with auto focusing height follower
4. Automatic Lubrication System for Mechanic
5. Taiwan "Hiwin" Ball Screw Rod
6. Laser Moving Control Card
7. Red Light Pointer
8. US imported Focus Lens
9. Japan SMC Gas system
10. Imported Germany Stowe the Bell / Niu Kate Reducer

Detailed Images

Product Name	Industrial Laser Cutting Machine
Model	HJZ -1000-3015
Laser Power	1000 Watts /1500 Watts /2000 Watts
Max. Cutting Thickness (mm)	8-10mm carbon steel 4-5mm stainless steel
Laser Type	Fiber Laser
Laser Technology	Germany Technology
XYZ Working area	1500 x 3000 x 150 (mm)
Max. Cutting Speed	0-24 Meters / Min (up to materials)
Transmission system	High Precision Gear Transmission
Table-driven system	Japanese Import Panasonic Servo Motor & Driving System
Focus Method	Dynamic Auto-Focusing System
Control Method	DSP Handle Offline Movement Control
Location precision	≤±0.05 mm
Re-location precision	±0.02 mm
Max. moving speed	100m/min
Laser wavelength	1070nm
Minimum line width	≤0.1mm
Supporting Format	PLT, DXF, BMP, AI
Power demand	380V / 50hz
Worktable max. load	1000 Kgs
Dimension (L*W*H)	4000 × 3000 × 2000mm
Control software	Professional Stainless Steel Laser Cutting Machine Software
Guarantee	2 Years Guarantee for Fiber Laser Source 12 Month Guarantee for Industrial Laser Cutting Machine
Training	WE Offer VCD Training Video for Easy Learning Engineer Overseas Installation & Training is also Available

Packing&Shipping

Our After sale Services
1) Workers of customers can come to our factory in Wuhan, China to get the most professional hand-by-hand training.
2) We can send engineers to customers' country and do training for workers in customers' target factory. However, tickets and
daily consumption like food and accommodation should be afforded by customers.
3) Remote training through Internet tools like Team-viewer, Skype and other instant communication software.

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory. And we have been in the laser field for more than 10 years.
Q: How long is your delivery time?
A: Generally, it will take 7 to 10 working days after receiving your advance payment. The specific delivery time depends on the
items and the quantity of your order.
Q: Do you provide samples? Is it free or extra ?
A: Yes, we could offer the sample for free charge, but customers should pay the courier cost.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shipment.
