SPECIFICATIONS

Brand Name: NONE

Choice: yes

Condition: New

High-concerned chemical: None

Origin: Mainland China

Type: Module

is_customized: Yes

Function description, application fields:

1. Home appliance maintenance:

suitable for home appliance maintenance

industry to brush and write color TV, DVD, computer motherboard, hard disk memory chips.

2. Product development:

Test chips are burned during the product development of the company. Product features:

1. USB 2.0 interface, with a speed of up to 12Mbps.

2. The reading and writing speed is super fast. It takes only 3 seconds to read EN25T80 and 9 seconds to write EN25T80. It is the fastest BIOS chip programmer on the market at present.

3. Automatically identify the chip model.

4. Automatically check whether the chip is in place.

5. Automatically select the chip power supply voltage.

6. Support PC software and programmer firmware upgrade.

7. Fully support 25 FLASH, 24 EEPROM, 25 EEPROM, 93

EEPROM.95EEPROM and other series of memory chips.

8. Small in shape, easy to carry, and almost as big as ordinary business cards.

9. Support Windows 2000, Windows XP, Windows Vista, Windows7, WIN8 and WIN10. (Note: For some WIN8 and WIN10 drivers, the system should be set before installation, and the installation of drivers is introduced below). EZP2023 software and driver link: EZP2023 software driver and tutorial: Please see the "Driver Installation Video" in

https://wwva.lanzoum.com/iq X7W0t95era driver installation for

installation, thank you!

Package 1

Package 2

Package 3

Package 4

Package 5

List of supported chip models:

XTXtect:
PN25F04A,PN25F04C,PN25F08B,PN25F08,PN25F16B,PN25F16,PN25F32,PN25F32B,PN25F64B,PN25F64,
PN25F128B,XT25F02D,XT25F04B,XT25F08B,XT25F16B,XT25F32B,XT25F64B,XT25F64BB,XT25F128

CHUANGFEIXIN:
CF25Q08BS,CF25Q16BS,CF25Q32BS,CF25Q64BS,CF25Q128BS,GM25Q16,GM25Q32,GM25Q64,
GM25Q128BS,

XMC:
XM25QE16B,XM25QE32B,XM25QW16C,XM25QW32C,XM25QW64C,XM25QW128C,XM25QW256C,
XM25QA64A,XM25QA128A,XM25RH256C

ZBIT Semi:
ZB25WD10A,ZB25WD20,ZB25WD40,ZB25WD80,

GIGADEVICE:
MD25T80,MD25D20,MD25D40,MD25D80,MD25D16.

TMC(93 eeprom):
TMC93LC46@8bit,TMC93LC56@8bit,TMC93LC57@8bit,TMC93LC66@8bit,TMC93LC86@8bit,
TMC93LC46@16bit,TMC93LC56@16bit,TMC93LC57@16bit,TMC93LC66@16bit,TMC93LC86@16bit,

Support chip
--------------------------------------------------------------------------------
Support 24, 25 and 93 series chips of most manufacturers in the market!

********************25  SPI  FLASH*******************************************************************

AMIC:
A25L05PU, A25L05PT,A25L10PT,A25L05PU,A25L20PT,A25L512, A25L010,
A25L10P, A25L020, A25L20P, A25L040, A25L40P, A25L080, A25L80P, A25L016, A25L16P, A25L032,A25LQ32A

ATMEL:
AT25F512, AT25F512A, AT25F512B, AT25F1024, AT25F1024A, AT25FS010,
AT25DF021, AT25F2048, AT25DF041A, AT25F4096, AT25FS040, AT26F004, AT26DF081A,
AT25DF161, AT26DF161, AT26DF161A, AT25DF321, AT25DF321A, AT26DF321

EON:
EN25F05, EN25LF05, EN25P05, EN25D10, EN25F10, EN25LF10, EN25P10, EN25D20, EN25B05,EN25B05T,
EN25F20, EN25LF20, EN25D40, EN25F40, EN25LF40, EN25D80, EN25F80, EN25Q80, EN25T80,EN25T80,
EN25B16, EN25B16T, EN25D16, EN25F16, EN25Q16, EN25T16, EN25B32, EN25B32T, EN25F32,EN25QH16,
EN25P32, EN25Q32, EN25B64, EN25B64T, EN25F64, EN25P64, EN25Q64, EN25F128, EN25Q128,EN25QH32,
EN25QH64,EN25QH128,

ES:
ES25P80, ES25P16,

ESMT:
F25L004A, F25L04UA, F25L008A, F25L08PA, F25L016A, F25L16PA, F25L32PA, F25L32QA,F25L32QA

MXIC:
MX25L512, MX25V512, MX25L1005, MX25L2005, MX25L4005A, MX25V4005, MX25L8005,
MX25V8005, MX25L1605D, MX25L1635D, MX25L3205D, MX25L3225D, MX25L3235D, MX25L3237D, MX25L6405D, MX25L12805D
KH25L4006E,KH25L8006E, KH25L80036, KH25L1606E, MX25V1005,  MX25U4035, MX25V4035,MX25V8035,MX25U8935,
MX25L8006E,MX25L1606E,MX25L1635D, MX25L1633E,MX25L1635D,  MX25L1608D, MX25L1608E, MX25U1635E,MX25L3225D
MX25L3237D,MX25L3236D,MX25L3206E, MX25L3235D,MX25U3235F, MX25U3235E, MX25L3208D,MX25L3208E,MX25L6455E,
MX25L6465E,MX25L6408D,MX25L6408E,MX25L6406E,MX25L6445E,MX25L6436E,MX25L12835E,MX25L12835F,MX25U12835F,
MX25L12845E,MX25L12836E,MX25L12865E,MX25L12855E,MX25L25635E,MX25L25635F,MX25L25639F,MX25L25735E,
MX25U25635F,MX25L25735F,MX66U51235F,MX66L51235F,MX25U5121E(1.8V),MX25U1001E(1.8V),MX25U2032E(1.8V)

NEXFLASH:
NX25P10, NX25P20, NX25P40, NX25P80, NX25P16, NX25P32

PMC:
PM25LV512A, PM25LV010A, PM25LV020, PM25LV040, PM25LV080B

SAIFUN:
SA25F005,SA25F010, SA25F020, SA25F040, SA25F080, SA25F160, SA25F320

SPANSION:
S25FL001,S25FL002,S25FL004A, S25FL008A, S25FL016A, S25FL032A, S25FL064A,S25FL0128

SST:
SST25VF512, SST25VF512A, SST25VF010, SST25VF010A,
SST25VF020, SST25VF020A, SST25VF040, SST25VF040A, SST25VF040B, SST25VF080B,
SST25VF016B, SST25VF032B, SST25VF064C

GIGADEVICE:
GD25Q512,GD25Q10,GD25Q20B,GD25Q21B,GD25Q40B,GD25Q41B,GD25LQ40,GD25F40,GD25F80,
GD25Q80,GD25Q16,GD25Q32B,GD25Q64,GD25Q128,GD25Q256,GD25Q256MC,GD25LQ05B(1.8v),
GD25LQ10B(1.8v),GD25LQ20B(1.8v),GD25LQ80B(1.8V),GD25LQ16(1.8v),GD25LQ32(1.8v),
GD25LQ64(1.8v)

ST:
M25P05A, M25P10A, M25PE10, M25P20, M25PE20, M25P40, M25PE40, M25P80,
M25PE80, M25PX80, M25P16, M25PE16, M25PX16, M25P32, M25PX32, M25P64, M25PX64, M25P128

WINBOND:
W25X10, W25X10A, W25X10AL, W25X10L, W25P20, W25X20,
W25X20A, W25X20AL, W25X20L, W25P40, W25X40, W25X40A, W25X40AL, W25X40L,
W25P80, W25X80, W25X80A, W25X80AL, W25X80L, W25P16, W25X16, W25P32, W25X32, W25X64
W25Q40,W25Q80,W25Q16,W25Q32,W25Q64,W25Q128,W25Q64FV,W25Q64FW,W25Q256，
W25P80,W25P16,W25P32,W25P64,W25P80,W25P16,W25P32,W25P64,W25Q05CL,W25Q10CL,
W25Q10EW(1.8V),W25Q20CL,W25Q20BW(1.8V),W25Q40BW(1.8V),W25Q80EW(1.8V),
W25Q16DW(1.8V),W25Q32DW(1.8V),W25Q64FW(1.8V),W25Q128FW(1.8V),W25Q256FW(1.8V)

BERGMicro:
BG25Q512A,BG25Q10A,BG25Q20A,BG25Q40A,BG25Q80A,BG25Q16A,BG25Q32A,BG25Q64A,BG25Q128A

BoyaMicro:
BY25D05AS,BY25D10AS,BY25D20AS,BY25D40AS,BY25D80AS,BY25D16AS,BY25D32AS,BY25D64AS,BY25D128AS,
BY25Q40AL(1.8V),BY25Q80AL(1.8V),BY25Q16AL(1.8V),BY25Q32AL(1.8V),BY25Q64AL(1.8V),BY25Q128AL(1.8V)

EXCELSEMI:
ES25M40A,ES25M80A,ES25M16A

FIDELIX:
FM25Q04A,FM25Q08A,FM25Q16A,FM25Q32A,FM25Q64A,FM25M04A(1.8V),FM25M08A(1.8V),FM25M16A(1.8V),
FM25M32A(1.8V),FM25M64A(1.8V),FM25M4AA(1.8V)

PCT:
PCT25VF512A,PCT25VF010A,PCT25VF020A,PCT25VF040A,PCT25VF080A

CHINGIS:
PM25LQ512,PM25LQ010,PM25LQ020,PM25LQ040,PM25LQ080,PM25LQ016,PM25LQ032

SANYO:
LE25FW406M,LE25FW406M

XTXtect:
PN25F04A,PN25F04C,PN25F08,PN25F08B

FIDELIX:
FM25Q04A,FM25Q08A,FM25Q16A,FM25Q32A,FM25Q64A

ZBITSemi:
ZB25D40,ZB25D80,ZB25D16,ZB25LQ40(1.8V),ZB25VQ20,ZB25VQ40,ZB25VQ80,ZB25VQ16,ZB25VQ32,ZB25VQ64,
ZB25VQ128

XMC:
XM25QH40B,XM25QH80B,XM25QH16B,XM25QH32B,XM25QH32C,XM25QH64A,XM25QH64B,XM25QH128A,XM25QH128B,
********************24  EEPROM*******************************************************************

ATMEL:
AT24C01, AT24C01A, AT24C01B, AT24C02, AT24C02A, AT24C02B, AT24C04, AT24C04A,
AT24C04B, AT24C08, AT24C08A, AT24C08B, AT24C16, AT24C16A, AT24C16B, AT24C32, AT24C32A,
AT24C32B, AT24C64, AT24C64A, AT24C64B, AT24C128, AT24C128A, AT24C128B, AT24C256, AT24C256A,
AT24C256B, AT24C512, AT24C512A, AT24C512B, AT24C1024, AT24C1024A, AT24C1024B

COMMON:
24C01,24C02,24C08,24C16,24C32,24C64,24C128,24C256,24C512,24C1024

MICROCHIP:
24C01,24C02,24C08,24C16,24C32,24C64,24C128,24C256,24C512,24C1024
24LC01,24LC02,24LC04,24LC08,24LC01,24LC16,24LC32,24LC64,24LC128,24LC1025
24AA01,24AA02,24AA04,24AA08,24AA16,24AA32,24AA64,24AA128,24AA256,24AA512,24AA1025

ST:
M24C01,M24C01R,M24C01W,M24C02,M24C02W,M24C02R,M24C08,M24C08R,M24C08W,M24C16,M24C16R,M24C16W,
M24C32,M24C32W,M24C64,M24C64W,M24C128,M24C128B,M24C256,M24C256A,M24C256B,M24C256W,ST24C01,
ST24C02,ST24C04,ST24C08,ST24C16
ST24W01,ST24W02,ST24W04,ST24W08,ST24W16,

ANACHIP:
AM24LC01,AM24LC02,AM24LC04,AM24LC08,AM24LC16

ROHM:
BR24C01,BR24LC01,BR24C02,BR24LC02,BR24C04,BR24LC04,BR24C08,BR24LC08,BR24C16,BR24LC16,BR24C32,BR24LC32,
BR24C64,BR24LC64

EOREX:
EM24LC01,EM24LC02,EM24LC04

RAMTRON:
FM24CL04,FM24CL04A,FM24C08A,FM24CL16,FM24CL64,FM24C64A,FM24C256

NSC:
NM24C02,NM24C04,NM24C08,NM24C64

ISSI:
IS24C01,IS24C02,IS24C04,IS24C08,IS24C16,IS24C32,IS24C64,IS24C128,IS24C256,IS24C512,IS24C1024

HOLTEK:
HT24C01,HT24C02,HT24C04,HT24C08,HT24C16,HT24C32,HT24C64,HT24C128,HT24C256,HT24C512,HT24C1024,
HT24LC01,HT24LC02,HT24LC04,HT24LC08,HT24LC16,HT24LC32,HT24LC64,HT24LC128,HT24LC256,HT24LC512,HT24LC1024,

FAIRCHILD:
FM24C01L,FM24C02L,FM24C03L,FM24C04L,FM24C05L,FM24C08L,FM24C9L,FM24C16L,FM24C17L,FM24C32L,
FM24C64L,FM24C128L,FM24C256L,FM24C512L,FM24C1024L

CATALYST:
CAT24C00,CAT24C01,CAT24C02,CAT24C21,CAT24C04,CAT24C08,CAT24C16,CAT24C32,CAT24C64,CAT24C128,
CAT24C2566,CAT24FC01,CAT24FC02,CAT24FC04,CAT24FC08,CAT24FC16,CAT24FC32,CAT24FC64,CAT24FC128,CAT24FC256,
CAT24LC02,CAT24LC04,CAT24LC08,CAT24LC16,CAT24LC32,CAT24LC64

HUAHONG:
K24C02,K24C04,K24C08,K24C16,K24C32,K24C64

HUAJIE:
K24C02,K24C04,K24C08,K24C16,K24C32,K24C64

********************93  EEPROM*******************************************************************

ATMEL:
AT93C46(16bit),  AT93C46(8bit),
AT93C46A, AT93C56(16bit),  AT93C56(8bit),AT93C57(16bit),
AT93C57(8bit),  AT93C66(16bit),AT93C66(8bit),AT93C86(16bit),
AT93C86(8bit), AT93C76@16bit

MICROCHIP：
93C46A,93C46B,93LC46A,93LC46B ,93C56A, 93C56B,93C56C(8b),93LC56A,93LC56B,
93LC56B,,93C66A,93C66A,93C66B,93C66C(8b),93LC66A,93LC66B,93C76A,93C76C(8b),93LC76A,
93LC76B,93C86A,93C86B,93LC86A,93LC86B,93LC86C(16b),93LC86C(8b)

ROHM：
BR93LC46, BR93LC46,BR93LC56,BR93LC56,BR93LC66,BR93LC66

ST：
ST93C06(16b),ST93C06(8b),M93S46,M93S46,ST93C46(16b), ST93C46(8b), ST93C47(16b)
ST93C47(8b), M93S56, M93S56,ST93C56(16b), ST93C56(8b), ST93C57(16b) ,ST93C57(8b)
ST93S66,ST93C66(16b),ST93C66(8b),ST93C67(16b), ST93C67(8b), ST93C86W(16b),
ST93C86W(8b)

ACE:
ACE93C46@8bit,ACE93C46@16bit,ACE93C56@8bit,ACE93C56@16bit,ACE93C66@8bit,ACE93C66@16bit

ANACHIP:
93C46,93C56,93C66

CATALYST:
CAT93C46@8bit,CAT93C56@8bit,CAT93C57@8bit,CAT93C66@8bit,CAT93C86@8bit,
CAT93C46@16bit,CAT93C56@16bit,CAT93C57@16bit,CAT93C66@16bit,CAT93C86@16bit

ATC:
ATC93C46@8bit,ATC93C46@16bit,ATC93C56@8bit,ATC93C56@16bit,ATC93C66@8bit,ATC93C66@16bit,
ATC93LC46@8bit,ATC93LC46@16bit

EOREX:
EM93LC46@8bit,EM93LC46@16bit,EM93LC56@8bit,EM93LC56@16bit,EM93LC66@8bit,EM93LC66@16bit,
EM93LC57@8bit,EM93LC57@16bit,EM93LC76@8bit,EM93LC76@16bit,EM93LC86@8bit,EM93LC86@16bit

ISSI:
IS93C46@16bit,IS93C56@8bit,IS93C56@16bit,IS93C66@8bit,IS93C66@16bit,IS93C76@8bit,IS93C76@16bit,
IS93C86@8bit,IS93C86@16bit

ICT:
ICT93C46@8bit,ICT93C46@16bit,ICT93C56@8bit,ICT93C56@16bit,ICT93C66@8bit,ICT93C66@16bit

HOLTEK:
HT93C46@16bit,HT93C56@16bit,HT93C66@16bit,HT93LC46@8bit,HT93LC46@16bit,HT93LC56@8bit,HT93LC56@16bit,
HT93LC66@8bit,HT93LC66@16bit,HT93LC76@8bit,HT93LC76@16bit,HT93LC86@8bit,HT93LC86@16bit

FAIRCHILD:
FM93C46,FM93C46A@8bit,FM93C46A@16bit,FM93C56,FM93C56A@8bit,FM93C56A@16bit,FM93C66,FM93C66A@8bit,
FM93C66A@16bit,FM93C76,FM93C76A@8bit,FM93C76A@16bit,FM93C86,FM93C86A@8bit,FM93C86A@16bit,
FM93S46,FM93S56,FM93S66

EXEL:
XL93C46,XL93CS46,XL93LC46,XL93C56,XL93CS56,XL93LC56,XL93C66,XL93CS66,XL93LC66,
XLS93C46,XLS93C56,XLS93C66

COMMON:
93C46@8bit,93C46@16bit,93C56@8bit,93C56@16bit,93C66@8bit,93C66@16bit,93C76@8bit,93C76@16bit,
93C86@8bit,93C86@16bit

AKM:
AK93C45@8bit,AK93C45@16bit,AK93C55@8bit,AK93C55@16bit,AK93C65@8bit,AK93C65@16bit,
AK93C75@8bit,AK93C75@16bit,AK93C85@8bit,AK93C85@16bit

YMC:
Y93LC46@8bit,Y93LC46@16bit,Y93LC56@8bit,Y93LC56@16bit,Y93LC66@8bit,Y93LC66@16bit,
Y93LC76@8bit,Y93LC76@16bit,Y93LC86@8bit,Y93LC86@16bit

RATO:
RT93C46,RT93LC46@8bit,RT93LC46@16bit

NSC:
NM93C46@8bit,NM93C46@16bit,NM93C56@8bit,NM93C56@16bit,NM93C66@8bit,NM93C66@16bit,
NM93C76@8bit,NM93C76@16bit,NM93C86@8bit,NM93C86@16bit

SEIKO：
S-93C76,S-93C66,S-93C56,S-93C46
********************************25 EEPROM******************************************************

ATMEL:
AT25010, AT25020, AT25040, AT25080, AT25160, AT25320, AT25640, AT25128, AT25256, AT25512

CATALYST:
CAT25C01, CAT25C01P, CAT25C01S, CAT25C01U, CAT25C02P, CAT25C02S, CAT25C02U, CAT25C11，
CAT25C03P, CAT25C03S, CAT25C03U, CAT25C04P, CAT25C04S, CAT25C04U, CAT25C05P, CAT25C05S,
CAT25C05U, CAT25C08P, CAT25C08S, CAT25C08U, CAT25C09P, CAT25C09S, CAT25C09U, CAT25C16P,
CAT25C16S, CAT25C16U, CAT25C17P, CAT25C17S, CAT25C17U, CAT25C32P, CAT25C32S, CAT25C33P,
CAT25C33S, CAT25C64P, CAT25C64S, CAT25C65P, CAT25C65S, CAT25C128P, CAT25C128S, CAT25C256P, CAT25C256S

COMMON:
25010, 25020, 25040, 25080, 25160, 25320, 25640, 25128, 25256, 25512

MICROCHIP:
25LC010A，25LC020A，25AA010A，25AA020A，25AA040, 25C040, 25LC040, 25AA080A, 25LC080B,25AA080B，
25LC080A, 25AA160, 25C160, 25LC160, 25AA320, 25C320, 25LC320, 25AA640, 25C640, 25LC640,
25LC128,25AA128，25LC256，25AA256，25LC512,25AA512，25LC1024,25AA1024

RAMTRON:
FM25040,FM25CL04,FM25L16,FM25C160, FM25640, FM25CL64,FM25L128，FM25L256,FM25L04B

ST:
ST25C01, ST25W01, ST25C02, ST25W02, ST25C04, ST25W04, ST25C08, ST25W08, ST25C16, ST25W16

TI:
TI2508，TI2516，TI2532, TI2532A, TI2564

XICOR:
X25010, X25020, X25021，X25040, X25041,X25043,X25045,X25080, X25160,X25170, X25320, X25640, X25256,X25512
X25F008,X25F016,X25F032,X25F064

********************************95 EEPROM******************************************************
M95010,M95020,M95040,M95080,M95160,M95320,M95640,M95128,M95256,M95512,M95M01,M95M02;
