Product Introduction:

TB6600 upgraded driver is a professional two-phase hybrid stepper motor driver, suitable for various domestic and foreign brands, current in 4.0A and below, outside diameter of 39,42,57 mm four wire, six wire, eight wire two-phase hybrid stepper motor. Suitable for all kinds of small and medium-sized automation equipment and instruments, such as: engraving machine, marking machine, cutting machine, laser phototypesetting, plotter, CNC machine tools, holding device, etc. The effect is best in high current operation equipment.

Product features:

• Signal input: single terminal, pulse/direction

• Subdivision Optional :1/2/4/8/16/32 Subdivision

• Output current :0.5A-4.0A

• Input voltage :9-42VDC

• The current is automatically halved at rest

• It can drive 4,6,8 wire two-phase and four-phase stepper motors

• Optical coupling isolated signal input, strong anti-interference ability

• With overheating, overcurrent, undervoltage locking, input voltage anti-reverse connection protection and other functions

• Compact size, easy to install

• External signal 3.3-24V universal, no series resistance

• The current is selected by a dip switch

• The interface is isolated by high speed optical coupling

• Eight subdivisions are adjustable

• Automatic half flow to reduce heat

• Large area heat sink is not afraid of high temperature environment

• Strong resistance to high-frequency interference

• Input voltage anti-reverse connection protection

• Overheat, overcurrent short circuit protection

• Failure warning light
