Guition ESP32S3 8M PSRAM 16M FLASH 5-inch IPS 800*480 high-definition LCD display module Capacitive touchwith WIFI and Bluetooth

Guition ESP32S3 8M PSRAM 16M FLASH 5-inch IPS 800*480 high-definition LCD display module Capacitive touchwith WIFI and Bluetooth

€62,16
€81,08 €62,16
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
Color
PayPal Klarna American Express

SPECIFICATIONS

Brand Name: GUITION

Choice: yes

Display Mode: 300:1

High-concerned chemical: None

Model Number: JC8048W550

Origin: Mainland China

Resolution: 800*480

is_customized: Yes

Data download link:


http://pan.jczn1688.com/directlink/1/HMI%20display/JC8048W550.zip


Hardware Feature of JC8048W550C_I



5.0” LCD-TFT Capacitive HMI touch display module

Supports WiFi and Bluetooth

Support lithium battery power supply

Capacitive touch

800 x 480 screen resolution

RGB 65K true-to-life colours

IPS glass panel

Onboard 240MHz LX6 MCU

520K Byte RAM

8 MB PSRAM

16 MB Flash memory

JST1.25 4 Pins (+5V, TX, RX, GND) TTL serial interface


Ver todos los detalles
