SPECIFICATIONS

Brand Name: DIYUSER

Choice: yes

Display Mode: 1

High-concerned chemical: None

Model Number: 1.3 Inch OLED

Origin: Mainland China

Resolution: 128*64

Type: OLED

is_customized: Yes

• High-Resolution Display :This 1.3 inch OLED display module offers a high-resolution of 128*64, ensuring clear and sharp visuals for your Arduino projects.

• Versatile Color Options :With its white and blue color drive chip, this LCD module provides vibrant and striking colors, enhancing the aesthetics of your devices.

• IIC I2C Resonate LED :Equipped with IIC I2C resonate LED, this display module ensures smooth and efficient operation, making it ideal for various electronics applications.

• Compact Size :Its compact size of 1.3 inches makes it easy to incorporate into your Arduino projects, offering a sleek and modern look while providing functionality.

• Easy to Use :This LCD module is easy to use, making it perfect for both beginners and experienced users in the electronics field.

• Durable Material :Made from durable materials, this display module is designed to withstand regular use, ensuring long-lasting performance.

Resolution: 128X64

Super wide viewing angle: more than 160 ° (maximum viewing angle display a screen)

Ultra-low power consumption: normal display 0.08W (far below the TFT display)

Wide supply range: DC 3V-5V (without any changes, directly compatible with common3.3V and 5v power supply system)

Industrial grade: Operating temperature range -30 degree~ 70 degree

The ultra-small size: (length) 35.5MM*(W) 33.5MM*(thickness) 4.3MM

Support for multiple operating modes: 3-wire SPl, 4 wire SPI, IIC

with chip select Cs signal, you can achieve multiple SPl or llC device on the same buswork

Compatible with 3.3V and 5v control chip l / 0 level (without any set, directly compatible)

Drive chip: SH1106
